Setting up Terraform for GCP

• Install gsutil
• Install Terraform

Start creating .tf files:

terraform {
  required_providers {
    google = {
      source = "hashicorp/google"
    }
  }
}

provider "google" {
  version = "3.5.0"
  credentials = file("myproject-123456-f72073802721.json")
  project = "myproject-123456"
  region  = "us-central1"
  zone    = "us-central1-a"
}

Create new VPC Network with subnets in Oregon and London

# Create new network called 'my-network'
resource "google_compute_network" "TF_NETWORK" {
  name = "my-network"
  auto_create_subnetworks = false
}

# Create subnet 172.16.1.0/24 in us-west1 (Oregon);
# Enable private API access & 1 minute 100% flow logging
resource "google_compute_subnetwork" "TF_SUBNET_1" {
  name          = "my-network-subnet-oregon"
  ip_cidr_range = "172.16.1.0/24"
  region        = "us-west1"
  network       = google_compute_network.TF_NETWORK.id
  private_ip_google_access = true
  log_config {
    aggregation_interval = "INTERVAL_1_MIN"
    flow_sampling        = 1.0
    metadata             = "INCLUDE_ALL_METADATA"
  }
}

# Create subnet 172.16.2.0/24 in europe-west2 (London)
# Add secondary IP range 192.168.200.0/26
resource "google_compute_subnetwork" "TF_SUBNET_2" {
  name          = "my-network-subnet-london"
  ip_cidr_range = "172.16.2.0/24"
  region        = "europe-west2"
  network       = google_compute_network.TF_NETWORK.id
  secondary_ip_range {
    range_name    = "tf-subnet-london-secondary-range"
    ip_cidr_range = "192.168.200.0/26"
  }
}

Create (ingress) firewall rules

# Allow ICMP, SSH, and DNS from RFC-1918 Private Address Space
resource "google_compute_firewall" "TF_FWRULE_1" {
  name    = "allow-ssh-and-dns-from-rfc-1918"
  network = google_compute_network.TF_NETWORK.name
  allow {
    protocol = "icmp"
  }
  allow {
    protocol = "tcp"
    ports = ["22"]
  }
  allow {
    protocol = "udp"
    ports = ["53"]
  }
  source_ranges = ["10.0.0.0/8","172.16.0.0/12","192.168.0.0/16"]
}

# Allow HTTP & HTTPS from Internet w/ logging enabled;
# applied to instances with network tag 'nginx' or 'apache'
resource "google_compute_firewall" "TF_FWRULE_2" {
  name    = "allow-http-and-https-from-internet"
  network = google_compute_network.TF_NETWORK.name
  enable_logging = true
  allow {
    protocol = "tcp"
    ports    = ["80", "443"]
  }
  target_tags = ["nginx", "apache"]
}

Create an External L7 Load balancer

# Create basic port 80 healthcheck
resource "google_compute_health_check" "TF_HEALTHCHECK" {
  name               = "check-website-backend"
  check_interval_sec = 15
  timeout_sec        = 3
  tcp_health_check {
    port = "80"
  }
}

# Create Backend service
 with backend timeout of 15 seconds and client IP session affinity
resource "google_compute_backend_service" "TF_BACKEND_SERVICE" {
  name                  = "website-backend-service"
  health_checks         = [google_compute_health_check.TF_HEALTHCHECK.id]
  timeout_sec           = 15
  session_affinity      = "CLIENT_IP"
}

# Create URL map (Load balancer)
resource "google_compute_url_map" "TF_URL_MAP" {
  name                  = "my-load-balancer"
  default_service       = google_compute_backend_service.TF_BACKEND_SERVICE.id
}

# Create HTTP target proxy
resource "google_compute_target_http_proxy" "TF_TPROXY_HTTP" {
  name                  = "my-http-target-proxy"
  url_map               = google_compute_url_map.TF_URL_MAP.id
}

# Create ssl cert/key HTTPS target proxy
resource "google_compute_ssl_certificate" "TF_SSL_CERT" {
  name        = "my-ssl-certificate"
  private_key = file("mykey.key")
  certificate = file("mycert.crt")
}
resource "google_compute_target_https_proxy" "TF_TPROXY_HTTPS" {
  name                  = "my-https-target-proxy"
  url_map               = google_compute_url_map.TF_URL_MAP.id
  ssl_certificates      = [google_compute_ssl_certificate.TF_SSL_CERT.id]
}

# Allocate External Global IP Address
resource "google_compute_global_address" "TF_IP_ADDRESS" {
  name                  = "gcp-l7-externalip-global"
}

# Create HTTP frontend
resource "google_compute_global_forwarding_rule" "TF_FWD_RULE_1" {
  name                  = "my-frontend-http"
  ip_address            = google_compute_global_address.TF_GLOBAL_IP_ADDRESS.address
  port_range            = "80"
  target                = google_compute_target_http_proxy.TF_TPROXY_HTTP.id
}

# Create HTTPS frontend
resource "google_compute_global_forwarding_rule" "TF_FWD_RULE_2" {
  name                  = "my-frontend-https"
  ip_address            = google_compute_global_address.TF_GLOBAL_IP_ADDRESS.address
  port_range            = "443"
  target                = google_compute_target_https_proxy.TF_TPROXY_HTTPS.id
}
